1JSCG-6-6 - Permanent Crimp Fittings - CG Series Fittings

Parker CG Series permanent crimp fittings are used on Parflex hoses and replace Parflex 55, 57, 58 and 58H Series fittings.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	Backordered

SKU 1JSCG-6-6

$24.37/each

Products specifications

Attribute name	Attribute value
UOM	EA	Materials of Construction	Steel
Hose I.D. (inch)	0.375"	Connection Thread Size	11/16"-16
Product Style	Female Seal-Lok - Swivel - Straight - Long	Shape	Straight Short
Division	Parflex Division	Connection Type	Seal-Lok
Length	2.73 inch	Port Size	3/8 inch
Materials of Construction	Steel	Dimensional Weight	0.0264 lb
