| UOM | EA | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Seal Material | D-Ring (Standard) |
| Configuration | Pressure Reducing/Relieving | Maximum Flow Rate | 6 GAL/MIN, 22.7 L/MIN |
| Wire Mesh Screen Included | N/A | Maximum Regulating Pressure | 3000 PSI, 210 BAR |
| Division | Hydraulic Cartridge Systems Division | Division | Hydraulic Systems Division |
| Operating Temperature | -35 to +200 °F | Flow Rate | 6 Gal/min |
| Actuation Type | Electrical | Maximum Flow Rate | 6 Gal/min |
| Power Consumption | 8.4 @ Max Reduced Pressure W | Maximum Operating Pressure | 350 bar |
| Maximum Operating Temperature | +93 °C | Minimum Operating Temperature | -37 °C |
| Body Material | N/A | Seal Material | D-Ring (Standard) |
| Flow Direction | Inlet port 2, Reducing port 1, Tank port 3 | Weight | 0.25 kg |
| Mounting Type | Screw in cartridge valve | Operation Type | Solenoid operated |
| Current | 0.73 at 12VDC, 0.365 at 24VDC A | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Configuration | Pressure Reducing/Relieving | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Hysteresis | 4% | Frequency | 200-600 Hz |
| Function | Proportional Pressure Reducing | Coil Type | SW7L Standard Short Coil |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Leak Rate | 230 De-Energized cm3/min |
| Cavity Size | C08-3L | Valve Material | All parts steel. All operating parts hardened steel |
| Installation Torque | 43-49 Nm | Maximum Inlet Pressure Rating | 350 bar |
| Override Functionality | N/A | Response Time | N/A ms |
| Maximum Pressure Setting | N/A psi | Maximum Tank Pressure | N/A psi |
| Wire Mesh Screen Included | N/A | Coil Nut Tightening Torque | 7-9.5 Nm |
| Maximum Drain Flow Rate | N/A cm3/min | Maximum Regulating Pressure | 3000 psi |
