| UOM | EA | Seal Material | Fluorocarbon |
| Override Functionality | N/A | Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR |
| Configuration | Pressure Reducing/Relieving | Maximum Flow Rate | 10 GAL/MIN, 37.5 L/MIN |
| Wire Mesh Screen Included | N/A | Maximum Regulating Pressure | 4000 PSI, 276 BAR |
| Mounting Type | Screw in cartridge valve | Override Functionality | N/A |
| Cavity Size | C10-3L | Minimum Operating Temperature | -15 °F |
| Flow Rate | 37.5 L/min | Operating Temperature | -26 to +204 °C |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Maximum Inlet Pressure Rating | 5000 psi |
| Maximum Tank Pressure | N/A psi | Flow Direction | Inlet port 1, Reducing port 2, Tank port 3 |
| Wire Mesh Screen Included | N/A | Function | Proportional Pressure Reducing |
| Power Consumption | 9 @ Max Reduced Pressure W | Current | 0.9 at 12VDC, 0.45 at 24VDC A |
| Response Time | N/A ms | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Regulating Pressure | 276 bar | Frequency | 200-600 Hz |
| Division | Hydraulic Cartridge Systems Division | Maximum Drain Flow Rate | N/A cm3/min |
| Maximum Flow Rate | 37.5 L/min | Coil Type | 1/2" Super Coil Low Watt (CCS) |
| Leak Rate | 492 @ 300 PSI (21 BAR), 946 @ 3000 PSI (210 BAR) cm3/min | Maximum Operating Temperature | +400 °F |
| Hysteresis | 4% | Seal Material | Fluorocarbon |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Pressure Setting | N/A psi |
| Body Material | N/A | Actuation Type | Electrical |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Configuration | Pressure Reducing/Relieving |
| Maximum Operating Pressure | 5000 psi | Weight | 1.3 lb |
| Coil Nut Tightening Torque | 7-9.5 Nm | Division | Hydraulic Systems Division |
| Installation Torque | 37-41 lb-ft | Operation Type | Solenoid operated |
