| UOM | EA | Seal Material | Fluorocarbon |
| Override Functionality | N/A | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Maximum Flow Rate | 5 GAL/MIN, 19 L/MIN | Wire Mesh Screen Included | Yes |
| Configuration | Side Cylinder Port | Maximum Regulating Pressure | 270-375 PSI, 19-26 BAR |
| Division | Hydraulic Cartridge Systems Division | Division | Hydraulic Systems Division |
| Operating Temperature | -26 to +204 °C | Flow Rate | 5 Gal/min |
| Actuation Type | Electrical | Maximum Flow Rate | 5 Gal/min |
| Power Consumption | 19 W | Maximum Operating Pressure | 3000 psi |
| Maximum Operating Temperature | +204 °C | Minimum Operating Temperature | -15 °F |
| Body Material | N/A | Seal Material | Fluorocarbon |
| Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 | Weight | 0.17 lb |
| Mounting Type | Screw in cartridge valve | Operation Type | Solenoid operated |
| Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Configuration | Side Cylinder Port | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Hysteresis | 3.5% | Frequency | 100-400 Hz |
| Function | Proportional Pressure Reducing | Coil Type | 1/2" Super Coil High Watt (CCP) |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Leak Rate | N/A cm3/min |
| Cavity Size | C08-3 | Valve Material | All parts steel. All operating parts hardened steel |
| Installation Torque | 20 lb-ft | Maximum Inlet Pressure Rating | 210 bar |
| Override Functionality | N/A | Response Time | 10 ms |
| Maximum Pressure Setting | N/A psi | Maximum Tank Pressure | N/A psi |
| Wire Mesh Screen Included | Yes | Coil Nut Tightening Torque | 3 lb-ft |
| Maximum Drain Flow Rate | 100 De-Energized, 750 In Regulating Zone @ 300 PSI (21 BAR) cm3/min | Maximum Regulating Pressure | 270-375 psi |
