DB-4 - Push-to-Connect Nickel Plated Instant Fittings - Prestolok PLP Metal

Parker's Prestolok PLP push-to-connect fittings offer improved throughput, increased efficiency, smaller footprints, faster assembly and leak-reducing innovation.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 38 days
Partner Available:	Backordered

SKU DB-4

$1.06/each

Products specifications

Attribute name	Attribute value
UOM	EA	Product Style	Boot
Connection 1 Size	1/4" (6 mm)	Connection 1 Type	Push-to-Connect
Tube Material	Nylon	Technology	Fluid & Gas Handling
Maximum Operating Temperature	200 °F	Seal Material	Nitrile
Gripping Ring Material	Stainless Steel	Application	Vacuum
Brand	Parker	Specifications Met	UL 94 V-0
Minimum Operating Temperature	-17.7 °C	Body Material	Brass, Nickel-plated
Region of Origin	United States	Maximum Operating Pressure	300 psi
Vacuum Pressure Rating	28 Inch-Hg	Materials of Construction	PVDF (Button)
For Fluid Type	Air	Division	Fluid System Connectors Division
Division	Fluid System Connectors Division	Industry	Automotive
