HS2TFL1/8-NT-SP - QPL PTFE AWG & Fractional 2:1 Heat Shrinkable Tubing

PTFE Heat Shrinkable Tubing protects components from heat, sparks and contaminants. When heated, the heat shrink tube conforms to the size and shape of the original object, providing a protective covering.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 54 days
Partner Available:	Backordered

SKU HS2TFL1/8-NT-SP

$4.88/foot

Products specifications

Attribute name	Attribute value
UOM	FT	Product Style	Light Wall
Recovered Inside Diameter	0.130	Minimum Expanded Inside Diameter	0.215
Maximum Operating Temperature	500	Minimum Expanded Inside Diameter	5.5
Size	1/8	Length per Package	100
Division	Parflex Division	Recovered Wall Thickness	0.008
Color	Natural	Product Type	Heat Shrink Tubing
Tube Material	Polytetrafluoroethylene (PTFE)	Application	High Temperature Applications
Specifications Met	AS 23053/12	Product Style	Fractional
Minimum Operating Temperature	-75	Recovered Inside Diameter	0.130
Weight	0.0032
