R4V105333009W30A1

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 71 days
Partner Available:	Backordered

SKU R4V105333009W30A1

$3,582.40/each

Products specifications

Attribute name	Attribute value
UOM	EA	Port Connection	NG32 / CETOP 10
Flow Rate	600 lpm	Operation Type	Pilot
For Fluid Type	Hydraulic Oil	Material	Cast Iron
Minimum Operating Temperature	-20 °C	Drain Option	Drain Line Internal
Switching Option	Vent Function: Solenoid not Activated, Unpressurized Circulation	Maximum Operating Temperature	60 °C
Actuation Type	Manual	Pressure Control Range	210 bar
Pressure Adjustment Control Type	Acorn Nut with Lead Seal	Marking	Standard
Seal Material	NBR	Product Series	Pressure valve
Mounting Option	Subplate Mounting	Input Voltage	110/120 VAC, 50/60 Hz
