R6V06595P0PN10VB1

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 98 days
Partner Available:	Backordered

SKU R6V06595P0PN10VB1

$9,934.68/each

Products specifications

Attribute name	Attribute value
UOM	EA	For Fluid Type	Hydraulic Oil
Material	Cast Iron	Maximum Flow Rate	500 lpm
Port Connection	NG25 / CETOP 08	Operation Type	Pilot
Actuation Type	Proportional	Maximum Operating Temperature	60 °C
Signal Input	'0-10 VDC	Pressure Adjustment Control Type	Without Mechanical max. Adjustment
Product Series	Pressure valve	Seal Material	NBR
Pressure Control Range	Up to 350 bar	Mounting Option	Subplate Mounting
Minimum Operating Temperature	-20 °C	Valve Type	R6V
Drain Option	Drain Line Internal
