PR05BB20ND - Reducing/Relieving Sandwich Valve, Pilot Operated – PR Series

Parker’s PR series pilot operated pressure reducing/relieving valves are used to regulate pressure in one area of a circuit at a set pressure below the normal system pressure.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 194 days
Partner Available:	Backordered

SKU PR05BB20ND

$2,345.28/each

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Valve Body Material	Ductile Iron	Size	NFPA D05; CETOP 5; NG10
Port Connection	Pressure Reducing in B w/check valve	Pressure Range (psi)	150 to 4500
Mounting Type	Subplate	Filter Efficiency Rating	ISO 4406 (1999); 18/16/13 (meet NAS 1638:7)
Actuation Type	Hydraulic Pressure	Media	Oil
Product Style	Pilot Operated Pressure Reducing/Relieving	Minimum Operating Temperature	-4 °F
Division	Hydraulic Valve Systems Division	Maximum Flow Rate	20 Gal/min
Maximum Operating Temperature	+122 °F	Seal Material	Nitrile
Weight	6.2 lb	Maximum Operating Pressure	345 bar
Body Material	Ductile Iron
