924455 - Replacement Elements - Low Pressure Filter Moduflow™ Plus Series

Name: 924455 - Replacement Elements - Low Pressure Filter Moduflow™ Plus Series
SKU: 924455
Price: 299.40 USD
Availability: LimitedAvailability

The patented Parker Moduflow™ Plus Series Low Pressure In-Line Suction/Return/Duplex Filter element features longer element life, increased dirt-holding capacity and requires fewer element changes, reducing system maintenance costs.

Availability:

1 Limited Stock

Olivette, MO

Partner Available:

30 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 924455

$299.40/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Micron Rating	40 µm	Length	single
Media	Wire Mesh	Filter Housing Series	CF2
Seal Material	Nitrile	Division	Engine Mobile Hydraulic and Fuel Filtration Division
For Fluid Type	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Micron Rating	40.0 MICRON
Length	Single	Product Type	Hydraulic Filter Element
Filter Element Type	Cartridge	Compatible Series	Moduflow™
Efficiency βx(C) ≥ 200	40 (nominal) µ	Collapse Pressure (psi)	73 psi
Pkg Qty	1	UOM	EA
Collapse Pressure (bar)	5 bar	Media Type	Stainless steel mesh
Seals	NBR: Nitrile	Parker Group	Filtration
Parker Division	Hydraulic Filter	Series	ParFit
Seals	NBR: Nitrile	Glue Endcaps Adhesive	Epoxy
Media Composition Detail	Single layer stainless steel mesh	Top Endcap Material	Steel
Bottom Endcap Material	Steel	Glue Side Seam Adhesive	Weld
Media	40 Micron Nominal	Media Type	Stainless steel mesh
Competitor	FLEETGUARD	Outer Support Cylinder Material	Steel tin plated
B Dimension	1.78 in (45.2 mm)	D Dimension	3.689 in (93.7 mm)
E Dimension	0.941 in (23.9 mm)	Efficiency βx(C) ≥ 200	40 (nominal) µ
Collapse Pressure (bar)	5 bar	Collapse Pressure (psi)	73 psi
