937393Q - Replacement Elements - Low Pressure Filter Moduflow™ Plus Series

The patented Parker Moduflow™ Plus Series Low Pressure In-Line Suction/Return/Duplex Filter element features longer element life, increased dirt-holding capacity and requires fewer element changes, reducing system maintenance costs.

Availability:	Backordered Estimated Lead Time: 45 days
Partner Available:	27 in stock

SKU 937393Q

$177.30/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Length	single	Filter Element	02QC Microglass
Filter Housing Series	RFP/ILP/DILP/TFP	Product Style	Hydraulic Filter
Length	Single	Product Series	RFP/ILP/DILP/TFP
For Fluid Type	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids	Division	Engine Mobile Hydraulic and Fuel Filtration Division
Filter Element Type	Cartridge	Product Type	Hydraulic Filter Element
Seal Material	Nitrile	UOM	EA
Efficiency βx(C) ≥ 1000	5 µ	Media	2 Micron Absolute
Seals	NBR: Nitrile	Media Type	Microglass
Collapse Pressure (bar)	5 bar	Collapse Pressure (psi)	73 psi
Efficiency βx(C) ≥ 200	4 µ	Pkg Qty	1
Parker Group	Filtration	Parker Division	Hydraulic Filter
Series	ParFit	Seals	NBR: Nitrile
Efficiency βx(C) ≥ 1000	5 µ	Media Composition Detail	Multilayer fiberglass with epoxy coated mesh on both sides
Glue Side Seam Adhesive	Epoxy	Glue Endcaps Adhesive	Epoxy
Media	2 Micron Absolute	Media Type	Microglass
Efficiency βx(C) ≥ 200	4 µ	Top Endcap Material	Glass reinforced nylon
Outer Support Cylinder Material	Steel tin plated	Bottom Endcap Material	Glass reinforced nylon
Collapse Pressure (bar)	5 bar	Collapse Pressure (psi)	73 psi
D Dimension	3.701 in (94 mm)	E Dimension	1.571 in (39.9 mm)
