6621-2000025 - Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose, Series 6621

Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose is for use in heater and radiator systems in heavy duty/high capacity vehicles and industrial equipment to 75 psi and 392°F, Series 6621

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 211 days
Partner Available:	10 in stock

SKU 6621-2000025

$117.81/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Standard Pack Qty (ft)	25
Hose I.D. (inch)	2	Minimum Burst Pressure (psi)	225
Cover Color	Red	Division	Hose Products Division
Maximum Operating Temperature	392 °F	Hose Inner Tube Material	Silicone
Media	Water	Design Factor	3:1
Minimum Operating Temperature	-76 °F	Cover Material	Silicone
Minimum Bend Radius	150.1 mm	Minimum Burst Pressure	225 psi
Hose Reinforcement Material	Multiple Plies of High Temperature Textile with Wire Helix	Specifications Met	SAE J20R1, Class A
Cover Structure	Greek-Corrugated	Application	Silicone Coolant
Package Type	Coil	Inside Diameter	51 mm
Weight	0.88 lb	Maximum Operating Pressure	5 bar
Outside Diameter	64 mm	Vacuum Pressure Rating	17.7 Inch-Hg
