3C24EF-EF25 - Soft Seat, In Line Hydraulic Check Valves - S6C and 3C Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 54 days
Partner Available:	Backordered

SKU 3C24EF-EF25

$322.73/each

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Fluorocarbon
Body Size (inch)	1 1/2	Inlet Port Size (inch)	1 7/8 - 12 UN
Cracking Pressure (psi)	25	Outlet Port Size (inch)	1 7/8 - 12 UN
Inlet Port Connection Type	Female SAE Straight Thread	Outlet Port Connection Type	Female SAE Straight Thread
Mounting Type	Threaded	Minimum Operating Temperature	400 °F
Maximum Operating Temperature	-40 °F	Maximum Flow Rate	125 Gal/min
Connection Size	1-7/8"-12 UN inch	Flow Direction	n/a
Body Material	Steel	Connection Type	Female SAE ORB to Female SAE ORB
Division	Quick Coupling Division	Seat Type	Soft Seat
Actuation Type	Mechanical	Configuration	n/a
Maximum Operating Pressure	3000 psi
