PD240 - Test Port, Diagnostic Quick Couplings, ISO 15171-1 - PD Series

Name: PD240 - Test Port, Diagnostic Quick Couplings, ISO 15171-1 - PD Series
SKU: PD240
Price: 56.20 USD
Availability: InStock

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

Manufacturer: Parker

Availability:

22 in stock

Kansas City, KS	18
Springfield, MO	2
TOPEKA, KS	2

Partner Available:

261 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU PD240

$56.20/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Tube Size (inch)	na
Connection Type	Female UNF	Connection Thread Size (inch)	7/16 - 20
Coupling Half	Female Coupler	Body Material	Steel
Valve Type	Non-spill	Flow Rate	0.8 Gal/min
Application	Diagnostic	Maximum Operating Pressure	6000 psi
Specifications Met	SAE J1502 / ISO 15171-1	Plating Type	Zinc with clear trivalent chromate
Product Type	Push to connect	Minimum Operating Temperature	-40 °F
Hex Size	0.81 inch	Maximum Operating Temperature	250 °F
Body Size	1/8 inch	Division	Quick Coupling Division
Seal Material	Nitrile
