150F-5-4 - Brass 45° Flare Fittings

Name: 150F-5-4 - Brass 45° Flare Fittings
SKU: 150F-5-4
Price: 23.14 USD
Availability: InStock

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:

15 in stock

TOPEKA, KS	9
Olivette, MO	6

Partner Available:

9 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 150F-5-4

$23.14/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Type	Female Pipe
Connection 1 Type	Flare	Connection 1 Thread Size	1/2-20 inch
Connection 1 Tube Outside Diameter	5/16 inch	Connection 3 Tube Outside Diameter	NA
Shape	90° Forged Elbow	Connection 3 Type	NA
Connection 2 Thread Size	1/4 inch	Connection 3 Thread Size	NA
Connection 2 Tube Outside Diameter	NA	Product Style	Flare to Female Pipe
Division	Fluid System Connectors Division	Division	Fluid System Connectors Division
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Technology	Fluid & Gas Handling
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Maximum Operating Temperature	250 °F
Brand	Parker	Specifications Met	SAE J512, SAE J513
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Minimum Operating Temperature	-53 °C
Maximum Operating Pressure	82.7 bar	Nut Material	Brass
O-Ring Material	Fluorocarbon	Body Material	Brass
