HO-252-4FP - High Pressure, High Flow, Steel Quick Couplings with Sleeve Lock - HO Series

Parker's high pressure and high flow quick couplers are ideal for use with high pressure hydraulic applications where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	28 in stock

SKU HO-252-4FP

$52.05/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection Type	Female NPTF
Coupling Half	Male Nipple	Maximum Operating Pressure	15000.0
Connection Thread Size	1/4 - 18	Body Material	Steel
Flow Rate	3.0 Gal/min	Division	Quick Coupling Division
Valve Type	Unvalved	Product Type	Manual Connect
Body Size	1/4 inch	Maximum Operating Temperature	250.0 °F
Application	Hydraulic, high pressure, high flow	Hex Size	0.81 inch
Plating Type	Electroless nickel	Minimum Operating Temperature	-40.0 °F

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
