797ST-10 - Hydraulic Constant Working Pressure Hose 6000 PSI - GlobalCore 797 Hose

Part of the GlobalCore line of robust yet lightweight hydraulic hose, Parker’s 797 hose is an easy-to-bend, easier-to-install 6000 PSI constant working pressure hose.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 19 days
Partner Available:	2192 in stock

SKU 797ST-10

$138.65/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (size)	-10
Hose Cover Type	SuperTough	Weight	0.54 lb/ft
Maximum Operating Pressure	42 MPa	Inside Diameter	16 mm
Hose Inner Tube Material	Proprietary Synthetic Rubber Compound	Compatible Fitting	77 Series
Maximum Operating Temperature	257 °F	Division	Hose Products Division
Size	-10	Minimum Operating Temperature	-40 °C
Cover Material	Synthetic Rubber Abrasion Resistant	Minimum Bend Radius	4-1/2 inch
Media	Petroleum Hydraulic Fluids	Outside Diameter	23.9 mm
Nominal Hose Inside Diameter	16 mm	Specifications Met	ISO 18752, Type DC
Application	Petroleum Base Hydraulic Fluids	Hose Reinforcement Material	4 or 6 Spirals of Steel Wire
