309P-6-4PP - Plastic Barbed Fittings, Parker Par-Barbs

Name: 309P-6-4PP - Plastic Barbed Fittings, Parker Par-Barbs
SKU: 309P-6-4PP
Price: 5.20 USD
Availability: InStock

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Manufacturer: Parker

Availability:

10 in stock

Kansas City, KS

Partner Available:

Backordered

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 309P-6-4PP

$5.20/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Color	Black
Product Style	Female Pipe to Male Pipe	Connection 1 Size	3/8"
Connection 1 Type	Male Pipe	Connection 2 Size	1/4"
Connection 2 Type	Female Pipe	Connection 2 Thread Size	1/4"
Connection 2 Hose I.D. (inch)	n/a	Shape	Reducer Bushing
Body Material	Polypropylene, Black	Configuration	Pipe to Pipe
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 1 Thread Size	3/8"	Connection 1 Hose I.D. (inch)	n/a
Connection 3 Size	N/A	Technology	Fluid & Gas Handling
Media	Water	Connection 1 Size	3/8
Color	Black	Division	Fluid System Connectors Division
Compatible Tube	Vinyl	Connection 2 Size	1/4
For Fluid Type	Water	Maximum Operating Temperature	104 °C
Maximum Operating Pressure	125 psi	Configuration	Pipe to Pipe
Connection 1 Type	Male NPT	Vacuum Pressure Rating	-29
Body Material	Polypropylene	Shape	Reducer Bushing
Division	Fluid System Connectors Division	Minimum Operating Temperature	-12 °C
Brand	Parker	Connection 3 Type	N/A
Connection 2 Type	Female NPT	Specifications Met	FDA
Application	Pneumatic Systems
