318P-24PP - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 25 days
Partner Available:	40 in stock

SKU 318P-24PP

Products specifications

Attribute name	Attribute value
UOM	EA	Color	Black
Connection 1 Type	Male Pipe	Connection 2 Hose I.D. (inch)	n/a
Body Material	Polypropylene, Black	Configuration	Pipe to Pipe
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 1 Hose I.D. (inch)	n/a	Connection 2 Size	N/A
Connection 2 Type	N/A	Shape	Hex Plug
Product Style	Male Pipe	Connection 1 Size	1-1/2"
Connection 1 Thread Size	1-1/2"	Division	Fluid System Connectors Division
Brand	Parker	Division	Fluid System Connectors Division
Technology	Fluid & Gas Handling	Application	Chemical Dispensing, Pneumatic Systems, Food Processing, Beverage Dispensing
Media	Water, Air, Other Compatible Fluids	Maximum Operating Pressure	125 psi
Maximum Operating Temperature	104 °C	Minimum Operating Temperature	10 °F
Body Material	Polypropylene	Specifications Met	FDA, NSF-51
Color	Black	Tube Material	Vinyl, Polyurethane, Rubber Hose
Dimensional Weight	0.5755 lb	Shape	Hex Plug
Configuration	Pipe to Pipe	Connection 1 Size	1-1/2
Connection 1 Type	Male NPT	Connection 2 Size	N/A
Connection 2 Type	N/A	Vacuum Pressure Rating	-29
Connection 3 Type	N/A	Connection 3 Size	N/A
Compatible Tube	Vinyl
