31GH-12N - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 25 days
Partner Available:	Backordered

SKU 31GH-12N

$2.02/each

Products specifications

Attribute name	Attribute value
UOM	EA	Color	White
Connection 2 Hose I.D. (inch)	n/a	Connection 1 Size	3/4"
Body Material	Nylon,White	Configuration	Pipe to Pipe
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 1 Thread Size	3/4"	Connection 1 Hose I.D. (inch)	n/a
Product Style	Garden Hose Thread	Connection 1 Type	Female Garden Hose
Connection 2 Size	N/A	Connection 2 Type	N/A
Shape	Garden Hose Nut	Shape	Garden Hose Nut
Body Material	Nylon	Vacuum Pressure Rating	-29
Connection 1 Type	Female Garden Hose	Maximum Operating Pressure	8.5 bar
Division	Fluid System Connectors Division	Brand	Parker
Application	Chemical Dispensing, Pneumatic Systems, Food Processing, Beverage Dispensing	Specifications Met	FDA, NSF-51
Configuration	Pipe to Pipe	Dimensional Weight	0.5755 lb
Media	Water, Air, Other Compatible Fluids	Connection 3 Size	N/A
Color	White	Connection 2 Type	N/A
Connection 1 Size	3/4	Minimum Operating Temperature	-40 °F
Connection 3 Type	N/A	Maximum Operating Temperature	93 °C
Division	Fluid System Connectors Division	Connection 2 Size	N/A
Compatible Tube	Vinyl	Tube Material	Vinyl, Polyurethane, Rubber Hose
Technology	Fluid & Gas Handling
