31HB-6N - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 25 days
Partner Available:	Backordered

SKU 31HB-6N

Products specifications

Attribute name	Attribute value
UOM	EA	Color	White
Connection 1 Size	3/8"	Connection 1 Type	Female Pipe
Connection 2 Hose I.D. (inch)	n/a	Body Material	Nylon,White
Configuration	Pipe to Pipe	Connection 3 Size	N/A
Connection 3 Type	N/A	Connection 1 Thread Size	3/8"
Connection 1 Hose I.D. (inch)	n/a	Connection 2 Size	N/A
Connection 2 Type	N/A	Shape	Swivel Nut
Product Style	Female Pipe	Configuration	Pipe to Pipe
Application	Chemical Dispensing, Pneumatic Systems, Food Processing, Beverage Dispensing	Maximum Operating Pressure	125 psi
Vacuum Pressure Rating	-29	Connection 1 Type	Female NPT
Body Material	Nylon	Color	White
Connection 3 Type	N/A	Connection 1 Size	3/8
Connection 2 Type	N/A	Specifications Met	FDA, NSF-51
Brand	Parker	Minimum Operating Temperature	-40 °F
Connection 2 Size	N/A	Maximum Operating Temperature	200 °F
Compatible Tube	Vinyl	Connection 3 Size	N/A
Technology	Fluid & Gas Handling	Media	Water, Air, Other Compatible Fluids
Tube Material	Vinyl, Polyurethane, Rubber Hose	Division	Fluid System Connectors Division
Shape	Swivel Nut	Division	Fluid System Connectors Division
