206-32 - Transportation Hose 350-3000 PSI - 206 Hose

Parker's 206 hose is a transportation hose that has a pressure range of 350-3000 PSI and is reinforced with one steel braid and one fiber braid making it excellent for rugged transportation applications.

Availability:	Backordered Estimated Lead Time: 98 days
Partner Available:	807 in stock

SKU 206-32

$75.31/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (size)	-32
Division	Hose Products Division	Application	Lubricating Oils
Media	Petroleum Hydraulic Fluids (Petroleum Base)	Maximum Operating Pressure	350 psi
Maximum Operating Temperature	302 °F	Minimum Operating Temperature	-48 °C
Specifications Met	SAE 100R5	Weight	1.32 kg/m
Outside Diameter	2.220 inch	Cover Material	Braid of Fiber
Inside Diameter	46 mm	Compatible Fitting	20 Series
Minimum Bend Radius	13-1/4 inch	Hose Inner Tube Material	PKR® Rubber
Hose Reinforcement Material	Braid of Fiber	Cover Color	Blue
Nominal Hose Inside Diameter	46 mm	Material	Rubber
Pkg Qty/UOM	66 FT	Pkg Qty	66
UOM	FT	Inner Diameter	1.813 Inch
Working Pressure	350 PSI (20 bar)	Mating Fitting Series	26, 20, 22
Parker Group	Fluid Connector	Inch/Metric	Inch
Parker Division	Hose Products	Inner Diameter	1.813 Inch
Inner Diameter Inch/mm	Inch	Material	Rubber
Application	Transportation	Hose Pressure Range	Low
Mating End Fitting Series	26, 20, 22	Hose Category	Transportation
Series	206	Working Pressure Range	250 to 499 PSI (17 to 34 bar)
