YAYA-11-8C - Type "M" Fitting Adapters

These fitting adapters connect to Type "M" Swivel end fittings and seal with a 58° cone.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	Backordered

SKU YAYA-11-8C

$153.50/each

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Male Type "M"
Connection 2 Thread Size	3/4"-16 UNF	Connection 1 Thread Size	1"-12 UNF
Connection 2 Type	Male Type "M"	Connection 2 Type	UNF Thread
Hex Size	25.4 mm	Connection 1 Size	1"-12 inch
Overall Length	1.88 inch	Connection 1 Type	Male
Maximum Operating Pressure	207 MPa	Materials of Construction	Stainless Steel AISI 316
Division	Parflex Division	Connection 2 Size	3/4"-16 inch

Product resources

Literature and Reference Materials

Catalog 4900 - Parflex Ultra High Pressure Thermoplastic Hose, Fittings and Accessories--CAT-4900 (PDF)
